duckicelake

The governed lakehouse catalog where masking is enforced on the bytes — not in the query.
An Iceberg REST catalog on DuckLake, with credential vending, byte-level PII masking, and an audit trail for every read. Built so nothing — human, engine, or LLM agent — can read data it shouldn't.

The problem

Every lakehouse governance story has the same hole: the engine reads the Parquet files, not your policies. Catalog-level masking rewrites SQL — which works right up until a client skips the view and opens the file. And the moment you hand out storage credentials, the catalog is out of the loop entirely. With LLM agents joining the query path, “please don’t look at the PII” is not a security model.

duckicelake closes that hole, along with two related ones:

1. Masking that survives any engine. Policies are enforced down to the bytes on object storage — an engine that never sends you SQL still can’t read what it shouldn’t.
2. Storage-credential enforcement on any S3. Scoped credentials on backends with STS, per-request remote signing on backends without — the catalog stays in the loop either way.
3. A lakehouse you can just INSERT INTO. Write with plain SQL in DuckDB or via Iceberg REST; readers on either path see it about a second later. No sync job.

Under the hood it’s an Iceberg REST Catalog proxy on top of DuckLake: DuckLake’s snapshot/schema/stats state is materialised into Iceberg-spec manifests on demand, so standard clients — PyIceberg, DuckDB’s iceberg extension, Trino, Spark — read Parquet straight from S3 and write back through spec commits. One pixi environment, no Docker.

See it in 60 seconds

pixi install
pixi run backends-up && pixi run ducklake-init && pixi run seed-governed
pixi run serve            # Iceberg REST catalog on :8181 — keep it running

In a second terminal:

SLEEP=0 pixi run demo     # authors tags/policies/roles over REST, then
                          # proves the mask: same query, per-principal rows

📥 Full quality: duckicelake-demo_no_code.mp4 · with source on screen: duckicelake-demo_with_code.mp4 (2:52)

Three hard problems, solved

1 · Masking enforced on the bytes — every engine, no exceptions

Tag a column pii.email, attach a mask, and flip "file-layer-masking": true. From that point the proxy maintains pre-masked Parquet copies of the table and serves masked principals shadow Iceberg metadata that points at them — while their vended credentials cover only the masked prefix. The base files return 403 at the storage layer.

That means the mask holds even for engines that never execute your SQL:

• the DuckDB iceberg extension (no view support, no scan planning) scans masked bytes transparently through the shadow metadata,
• PyIceberg and raw S3 reads get al*** because that’s what’s in the files they’re allowed to touch,
• and a DuckLake-direct DuckDB session gets a reader role whose row-level security hides the base files entirely,
• and Apache Spark and Trino, connecting via the Iceberg REST catalog with vended credentials (uri + token, nothing engine-specific), load the shadow metadata + scoped session creds and read masked values — verified end-to-end on real AWS S3 (see Receipts).

No other open catalog we’ve found does this. Catalog-level masking (view rewriting) is common; masked physical copies + shadow metadata + credential scoping is not. The cheap tier is still there — policies default to catalog-level (masking views + metadata signals, no extra storage) and you opt tables into byte-level per policy.

What this means for the ecosystem: governance lives in the catalog and the object store, not the engine. Any Iceberg-REST reader — Spark, Trino, DuckDB, PyIceberg, and whatever ships next — gets correct masked results with zero engine-side policy code and no trust placed in the engine, across any S3-compatible backend (verified on MinIO, Hetzner, and AWS). Governance stops being per-engine integration work and becomes a property of the table.

One policy set, per-principal results:

P=localhost:8181/v1/lake/governance; H='content-type:application/json'
curl -sX POST $P/tags        -H $H -d '{"namespace":"pii","name":"email"}'
curl -sX POST $P/object-tags -H $H -d '{"object-kind":"column","schema":"analytics","object":"customers","column":"email","tag-namespace":"pii","tag-name":"email"}'
curl -sX POST $P/masking-policies   -H $H -d '{"name":"mask_email","signature":"(val VARCHAR)","body":"left(val, 2) || '\''***'\''","unmasked-roles":["pii_reader"]}'
curl -sX POST $P/policy-attachments -H $H -d '{"policy-kind":"masking","policy-name":"mask_email","target-kind":"tag","tag-namespace":"pii","tag-name":"email"}'
curl -sX POST $P/roles       -H $H -d '{"name":"pii_reader"}'
curl -sX POST $P/role-grants -H $H -d '{"role":"pii_reader","principal":"alice"}'

Now SELECT * FROM analytics.customers answers differently by caller — same table, same query:

 principal bob (no roles)              principal alice (pii_reader)
 id │ email          │ mrr             id │ email             │ mrr
────┼────────────────┼──────          ────┼───────────────────┼──────
  1 │ al***          │ 2400             1 │ alice@example.com │ 2400
  2 │ bo***          │ 1800             2 │ bob@personal.io   │ 1800

Row-access policies stack the same way (boolean keep-predicates, AND-ed, evaluated on raw values before masking), and every decision lands in the audit trail. Full model — tag cascade, one-mask-per-column, upsert/rotate semantics, the hardening list from two adversarial review passes — in docs/REFERENCE.md.

Receipts: masked_export.py · byte-proof tests in test_governance_phase4.py (masked principal’s creds: 403 on base keys, 200 on masked copies) · run SLEEP=0 pixi run demo and read the SQL it prints.

2 · Credential enforcement on any S3 — with or without STS

Vended credentials are how the byte-level guarantees reach clients, so the proxy speaks four enforcement dialects and picks per backend:

The S3 gateway closes the last gap in the no-STS story. DuckDB’s httpfs can’t remote-sign like PyIceberg, so DuckLake-direct clients historically got a long-lived static key + a coarse bucket policy — the one credential in the stack that didn’t expire and wasn’t scoped per request. With the gateway enabled, the proxy exposes its own S3-compatible endpoint and vends a credential it mints and controls: the access-key-id packs the caller’s identity + scope + an expiry; the secret is HMAC(gateway_secret, access-key-id), so it’s stateless and unforgeable. DuckDB signs each request with it; the gateway verifies that SigV4, runs the same authorize_sign governance the remote signer does (fail-closed, per-object, per-method), re-signs with the root key, and forwards to the backend. Result: short-lived, scoped, live-revocable credentials with the root key never leaving the proxy — STS-grade security on a backend with no STS. Opt-in via [s3_gateway] enabled = true (secret + url required); off by default, leaving the static-key tier untouched.

The no-STS path was verified against live Hetzner Object Storage (2026-07-03): the full multipart lifecycle through the signer, PyIceberg driving its own S3V4RestSigner against the proxy, file-layer masked exports materialised on Hetzner with base-byte denial, and the generated bucket policy enforced — details in OPERATIONS.md and MISSING.md. The S3 gateway was live-verified on the same backend (2026-07-16): a DuckDB httpfs client reads through the gateway and gets rows, while out-of-scope, expired, and wrong-secret credentials are denied before any backend call — and its SigV4 verifier interops with botocore’s own signer by construction (unit-tested against it). AWS runs the same code paths but hasn’t been exercised against live AWS yet; it’s unit-tested only.

For file-layer masking on a no-STS backend, a masked reader needs a confined static key (registered confined=true) so the proxy can vend it the masked export instead of failing closed — otherwise the masked table reads empty. Setup + guarantees in docs/file_layer_no_sts.md.

3 · INSERT INTO your lakehouse

Two write paths, one table, no sync job:

• Iceberg REST commits (PyIceberg / Trino / Spark): manifest chain + metadata.json built inline as part of the commit.
• Plain SQL (DuckDB ATTACH 'ducklake:…', then INSERT / UPDATE / DELETE): a Postgres LISTEN/NOTIFY hook fires on the DuckLake commit and the proxy eagerly materialises the full Iceberg metadata chain on S3 — so a fresh PyIceberg/Trino/Spark reader hits a warm chain on its first LoadTable, about a second after the write.

The eager path is a latency optimisation, not the source of truth: if the listener is off or dies, the lazy LoadTable materialisation still serves correct data. One listener per fleet is elected via PG advisory lock, with a startup catch-up scan (notify.py).

The recording ends on the identity check: DuckLake HEAD == Iceberg current-snapshot-id, deterministically. Snapshot ids aren’t random, so the two systems’ state lines up directly when you’re debugging.

What makes it different

Every row of that table is backed by a runnable script or test in this repo — see Receipts.

The ecosystem: duckicelake + lakesh + agents

  Claude / any MCP agent          humans (REPL / scripts)
            │                              │
            ▼                              ▼
      lakesh mcp  (read-only default)   lakesh / psql-style shell
            └──────────────┬──────────────┘
                           ▼
                duckicelake proxy :8181
        masking · row policies · RBAC · audit
        vended scoped credentials / remote signing
                           │
                 ┌─────────┴─────────┐
                 ▼                   ▼
           S3 (Parquet)        Postgres (DuckLake)

lakesh is the companion CLI: a DuckDB-powered SQL shell for Iceberg REST and DuckLake catalogs, with connection profiles, OAuth2 token handling, a psql-style REPL, one-shot exec for scripts — and an MCP server so LLM agents query the catalog through the same governed plumbing. Its DuckLake profile accepts the STS session tokens duckicelake vends, so a governed principal’s session is one lakesh -p governed away.

The agent story, end to end: give the agent’s token a role without the unmasked-roles bypass, point lakesh mcp at the proxy, and the agent reads al*** where an analyst holding pii_reader reads alice@example.com — through the same API, every access audited, and the MCP server refuses writes unless you explicitly opt in (LAKESH_MCP_WRITE=1). Agents can’t see PII by construction, not by prompt.

Actor-aware sessions — no separate agent token needed

You don’t have to mint a distinct agent principal. A trusted broker (a gateway fronting the proxy for many end users) can assert, per request, both the effective principal and a session context — actor=human|agent, channel=rest|mcp — with delegate=1. The context rides into the policy engine as synthetic actor:* / channel:* role tags, so the same unmasked-roles machinery drives it: grant humans the bypass tag, withhold it from agents, and a sensitive column masks for an agent while a human sees cleartext — same user, same token, decided by who’s driving the session. Agent sessions are also read-only at the data plane (write vends refused). Delegation is opt-in, so existing callers are unaffected. See docs/actor_aware_governance.md.

Agent masking is airtight by construction. Cooperative masking (below) can be sidestepped by a client that names the base table directly — fine for a trusted human, not for an LLM agent. So whenever a mask applies to an actor:agent session, the proxy forces file-layer enforcement: the agent’s credentials are scoped to the masked export only, base bytes are physically denied, and a qualified SELECT … FROM ns.table gets a 403 instead of cleartext (unqualified names still resolve to the masked view). It stays a per-agent property — humans on the same table keep cooperative masking. On by default; opt out with DUCKICELAKE_AGENT_FILE_LAYER=0.

duckicelake also ships a native governed MCP server (duckicelake.mcp_server) where connecting is the agent signal: every call is stamped actor=agent, channel=mcp, and its tools (list_namespaces, list_tables, describe_table, query) execute read-only SQL server-side and return rows only — the agent never receives the DSN or S3 credentials, so it can’t slip past a masked view to the base table.

For agents reaching the catalog across a network or between agents, the same four tools are also exposed over SMCP (Secure MCP) via duckicelake.smcp_interface: MCP’s tool model wrapped in api_key/JWT auth (RS256 so clients can’t forge tokens), authenticated per-message encryption, and replay protection. An SMCP session vends actor=agent, channel=smcp, so it inherits the same airtight agent governance (forced file-layer masking, read-only) — a qualified base-table query is denied, not leaked. The server binds loopback (front it with TLS for the wss:// edge); the caller’s verified client_id maps to the acting principal. Put the SMCP checkout on PYTHONPATH, point DUCKICELAKE_SMCP_CONFIG at an SMCP TOML (secrets + RS256 keys), and run python -m duckicelake.smcp_interface.

pixi run demo-lakesh      # lakesh: REST read vs the vended masked view

📥 Full quality: lakesh-companion-demo.mp4 (0:55)

Defense in depth

Two enforcement tiers, chosen per policy:

• Cooperative (default). Masking views + metadata signals; DuckLake- direct sessions get transparent masking via SET search_path, so unqualified queries hit the masked view without the client changing a line. Cheap, no extra storage; a client that names the base table with base credentials can still read raw — right for trusted analysts. (AI-agent sessions are auto-upgraded to the airtight tier — see Actor-aware sessions.)
• Airtight (file-layer-masking: true). Pre-masked Parquet + shadow metadata + credentials that physically can’t reach base bytes + PG row-level security hiding the base files (per-principal, per-vend LOGIN roles; the RLS predicate plans as a once-per-scan hashed set-membership test, not a per-row call).

Failure posture is tiered too: the airtight surfaces and the credential vend always fail closed; the cooperative tier fails open by default (a governance error degrades to unmasked-with-audit) and DUCKICELAKE_GOVERNANCE_FAIL_CLOSED=1 hardens it. Reserved duckicelake.* properties can’t be forged by write tokens, export SQL is injection-escaped, and renames/drops carry or purge their policies so masks never silently lapse. The full hardening inventory — audited in two adversarial review passes — is in docs/REFERENCE.md.

Receipts

Claims above, and where they’re proven:

• 180+ pytest tests across 18 files, all against a live proxy + MinIO + Postgres stack — including the byte-proofs (masked principal’s creds 403 on base Parquet, 200 on masked copies), the fail-closed regression suite, STS policy-degradation units, and the remote-signing path end-to-end with PyIceberg’s own signer class. CI runs the suite plus the full duckdb-client e2e demo (20+ assertion blocks) on every push.
• ~349 req/s cache-hit LoadTable at concurrency 32 on one machine; ~1s read-after-write across paths; masked scans on par with base scans at 1M rows; 4-worker fleet survives killing a worker mid-run.
• Hetzner Object Storage: live-verified full sweep (2026-07-03) — remote signing, multipart, byte-level masking on real object storage, bucket-policy enforcement.
• Real AWS S3 + STS: live-verified (eu-central-1, 2026-07-07) — the STS path a no-STS backend can’t exercise. AssumeRole vends per-request session credentials scoped by an inline policy, and AWS enforces it: a masked principal’s creds read the masked export (200) and get 403 on the raw base Parquet. Confirmed through external query engines, not just DuckDB — Apache Spark 3.5 and Trino 446 each read the table via the Iceberg REST catalog with vended credentials and saw only masked values. The same governance ran unchanged across three storage backends (MinIO, Hetzner, AWS); only [s3]/[sts] config differs.
• Iceberg v3, early: v3 writes end-to-end (via the pyiceberg_v3 shim), deletion vectors written as spec-correct Puffin files byte-by-byte (puffin.py, verified in test_puffin.py), VARIANT/GEOMETRY types.
• Multi-tenant: one proxy serves many isolated catalogs (own PG schema + S3 prefix + reader roles per tenant, account-scoped routing) — docs/REFERENCE.md.
• Known gaps, written down. MISSING.md lists what’s not done — worth reading before you deploy.

Quickstart

pixi install
pixi run backends-up     # Postgres + MinIO
pixi run ducklake-init   # creates bucket + default namespace
pixi run serve           # Iceberg REST catalog on :8181 (single worker, --reload)
# OR
pixi run serve-hi        # 4 uvicorn workers, no reload — closer to prod shape

In another terminal:

pixi run seed-governed   # sample data + a demo mask (bob masked, alice not)
pixi run smoke           # catalog-only smoke
pixi run duckdb-client   # the full e2e demo (20+ assertion blocks)
pixi run demo            # governance walkthrough + masked-vs-clear SQL proof
pixi run test            # the pytest suite

Everything runs out of a single pixi environment — no Docker. Teardown: pixi run backends-down. Production backends (real S3 + STS, or Hetzner with remote signing) are a config swap — see docs/REFERENCE.md and OPERATIONS.md.

Query it

PyIceberg

from pyiceberg.catalog.rest import RestCatalog

cat = RestCatalog(
    "lake", uri="http://127.0.0.1:8181", warehouse="lake",
    **{"s3.endpoint": "http://127.0.0.1:9000",
       "s3.access-key-id": "minioadmin", "s3.secret-access-key": "minioadmin",
       "s3.region": "us-east-1", "s3.path-style-access": "true"})
print(cat.load_table("analytics.customers").scan().to_arrow().to_pandas())

DuckDB iceberg extension

INSTALL httpfs; LOAD httpfs; INSTALL iceberg; LOAD iceberg;
CREATE OR REPLACE SECRET ice_s3 (
    TYPE S3, KEY_ID 'minioadmin', SECRET 'minioadmin',
    REGION 'us-east-1', ENDPOINT '127.0.0.1:9000',
    USE_SSL false, URL_STYLE 'path');
ATTACH 'lake' AS ice (
    TYPE ICEBERG, ENDPOINT 'http://127.0.0.1:8181',
    AUTHORIZATION_TYPE 'none', ACCESS_DELEGATION_MODE 'none');
SELECT * FROM ice.analytics.customers;

lakesh

lakesh config init && lakesh doctor
lakesh exec -q 'SELECT count(*) FROM analytics.customers'
lakesh                    # REPL: \l, \d analytics, SELECT …

Time-travel, joins across snapshots, per-client footnotes, and the governed-read walkthrough: docs/REFERENCE.md.

Current state

Alpha. Shipped and tested today: the full Iceberg REST surface (v2 + v3), the hybrid write model, tags/RBAC/masking/row policies with both enforcement tiers, per-principal reader roles + RLS, credential vending across all three backend dialects, multi-catalog tenancy, OAuth2, audit, Prometheus observability.

Known boundaries — the short version (full list in MISSING.md):

• Dev-stack Postgres runs trust auth; RLS authentication is only real under production scram-sha-256 + TLS (OPERATIONS.md has the recipe).
• AWS STS is code-correct and unit-tested but not yet run against live AWS; Hetzner is live-verified.
• Not yet built: a dedicated agent-role convention layer, Spark/Trino integration tests, HA/ops hardening (tracing, dashboards, chaos runs).

Docs map

In this documentation

• Actor-aware governance (broker delegation + session context)
• File-layer masking without STS (e.g. Hetzner Object Storage)
• Multi-catalog isolation (qod integration)
• duckicelake reference
